161/327
Building Technologies Basic Documentation LMV5... CC1P7550en
8 Display and operating unit AZL5 22.05.2018
8.3.7 Adaption of the load controller's PID parameters
Sequence steps of adaption (self-setting):
1) Starting the adaption
Using the AZL5 menu, the heating engineer manually activates the adaption function of
the load controller.
After selecting menu item Adaption (within the parameterization of the load controller),
the following display appears:
, The pointer is positioned on Start Adaption. Adaption is activated by pressing Enter
S t a r t A d a p t i o n
w i t h E N T E R 6 0
S e t p o i n t : 7 0 . 0 ° C
A c t V a l : 6 0 . 0 ° C
Adaption starts after pressing Enter whereupon the following text appears:
A d a p t i o n a c t i v e
L o a d : 5 2 . 0 %
A c t V a l : 6 0 . 0 ° C
C a n c e l w i t h E S C
Depending on the adaption step, the following displays appear, alternating with the
display shown above:
A d a p t i o n a c t i v e
S e t t l i n g P h a s e
m a x 1 0 m i n
C a n c e l w i t h E S C
A d a p t i o n a c t i v e
T e m p S e t b a c k
A c t V a l : 6 0 . 0 ° C
C a n c e l w i t h E S C
A d a p t i o n a c t i v e
H e a t i n g
m a x 1 0 m i n
C a n c e l w i t h E S C
