Building Technologies Basic Documentation LMV5... CC1P7550en
15 Technical data 22.05.2018
15 Technical data
15.1 LMV5 and AZL5
Mains voltage AC 120 V
-15% / +10%
AC 230 V
-15% / +10%
Β
Note!
Only for use in earthed networks!
Transformer AGG5.210 / AGG5.220
- Primary side
- Secondary side 1
- Secondary side 2
AC 120 V
AC 12 V
2 x AC 12 V
AC 230 V
AC 12 V
2 x AC 12 V
Mains frequency 50 / 60 Hz ±6% 50 / 60 Hz ±6%
Power consumption <30 W (typically) <30 W (typically)
Safety class I with parts according to II and III as per
DIN EN 60730-1
Degree of protection of housing IP00 in accordance with DIN EN 60529
IP40 in accordance with DIN EN 60529
must be ensured through adequate
installation of the LMV5 by the burner or
boiler manufacturer
Mode of operation Type 2B in accordance with DIN EN
60730-1
Rated impulse voltage Rated impulse voltage in accordance with
DIN EN 60730-1; chapter 20 (overvoltage
class III)
Mains voltage and power supply for EMC
emitted interference tests
The emitted interference measurement is
tested with mains voltage and maximum
power consumption
LMV5
