VPN tunnel between SCALANCE M-800 and S612
3.3 Secure VPN tunnel with certificates
SCALANCE M-800 Getting Started
Getting Started, 06/2015, C79000-G8976-C337-04
129
The following files will be saved in the project directory:
● Configuration file: projectname.M-800.txt
● PKCS12 file: projectname.string.M-800.p12
● Remote certificate: Projectname.group1.S612.cer
The configuration file contains the exported configuration information for the SCALANCE M-
800 including information on the additionally generated certificates. Follow the instructions in
the configuration file.
Configuring SCALANCE M-800
3.3.3.1
Loading a certificate
Requirement
● The correct time is set on the SCALANCE M, refer to the section Setting the time
(Page 23).
● Certificates are available.
You saved the required certificates on the PC in the last section and assigned a
password for the private key.
Transfer the certificates for the SCALANCE M to the Admin PC.
1. Click on "System" > "Load & Save" in the navigation area and on the "Password" tab in
the content area.
2. For "Password" and "Password Confirmation", enter the password Di1S+Xo?, that you
specified for the PKCS12 file.
3. Select "Enabled" and click "Set Values".
