1.3 Design of the CP 340
PtP coupling and configuration of CP 340
16 Manual, 04/2011, A5E00369892-03
1.3 Design of the CP 340
Introduction
The CP 340 communication processor is supplied with an integrated serial interface.
Positions of module elements
The figure shows the positions of the module elements on the front panel of the CP 340
communication processor.
,QGLFDWRUHOHPHQWV
)URQWSDQHOGRRU
,QWHJUDWHGLQWHUIDFH
)L[LQJVFUHZ
6)
7['
5['
Figure 1-1 Positions of the module elements on the CP 340 communication processor
