PtP coupling and configuration of CP 340
Manual, 04/2011, A5E00369892-03
93
Configuring and Parameterizing the CP 340
5
5.1 Parameterization Options
Configuration options
You configure and parameterize the module variants of the CP 340 using STEP 7 or the
CP 340: Point-to-Point Communication, Parameter Assignment user interface.
Table 5- 1 Configuration options for the CP 340
Product Order number Configurable using the
parameter assignment user
interface
Under STEP 7
CP 340–RS 232C 6ES7 340–1AH00–0AE0* As of V1.0 As of V2.1
CP 340–RS 232C 6ES7 340–1AH01–0AE0**
CP 340–20mA-TTY 6ES7 340–1BH00–0AE0**
CP 340–RS 422/485 6ES7 340–1CH00–0AE0**
As of V3.0 As of V3.0
CP 340-RS 232C 6ES7 340-1AH02-0AE0***
CP 340-20mA-TTY 6ES7 340-1BH02-0AE0***
CP 340-RS 422/485 6ES7 340-1CH02-0AE0***
as of version V5.1.5 As of V5.0
* You can also use the parameter assignment user interface as of V3.0 to configure this module, although you will then
only be able to parameterize the drivers integrated into the module firmware (not the printer drivers).
** You can also use the parameter assignment user interface as of V1.0 to configure these modules, although you will then
only be able to parameterize the drivers available on the parameter assignment user interface (not the printer drivers).
*** The new functionalities (FW update and ID data (read)) are only supported as of STEP 7 V5.2.
