Siemens SIMOTICS XP User Manual

Spare parts
10.10 Machine parts
1MB..1/2/3/4 - shaft heights 63 ... 355
Operating Instructions, 06/2020, A5E44455710A
135
10.10 Machine parts
10.10.1 Part lists
Part
Description
Part
Description
1.00
DE bearings
Terminal box, complete
1.30
Screw
5.37
Spring lock washer
1.40
Bearing shield
5.42
Terminal box housing, including seal
1.43
Shaft sealing ring
5.43
Entry plate
1.44
Bearing cover DE, inner
5.44
Terminal box upper section
1.45
Screw (bearing cover)
5.45
Enclosure
1.46
Cover ring
5.46
Screw
1.49 Screw 5.47 Screw
1.50
Flanged nut
5.48
Spring lock washer
1.56
Spacer washer
5.49
Screw
1.58
Spring washer
5.51
Flanged nut
1.60
Rolling bearing
5.52
Cable entry
1.61
Spring band for end shield hub
5.55
Nut
1.63
Condensation drain plug
5.64
Spring lock washer
1.65
Grease nipple
5.65
Screw
3.00
Rotor, complete
5.70
Terminal clamp
3.38
Fitted key
5.76
Terminal plate / contact bracket
4.00
Stator, complete
5.78
Spring lock washer
4.04
Eyebolt
5.79
Screw
4.05
Washer
5.81
Screw
4.07
Housing foot
5.83
Seal
4.08
Housing foot, left
5.84
Terminal box cover
4.09
Housing foot, right
5.85
Terminal box cover including seal (optional screw)
4.10
Spring lock washer
5.89
Screw
4.11
Screw
5.93
Seal
4.12
Nut
5.96
Screw plug
4.18 Rating plate 5.97 Locknut
4.19
Self tapping screw or slotted pin
5.98
Sheet metal nut
4.20
Cover
5.99
Adapter plate
4.30
Contact bracket
6.00
Bearings, NDE
4.31
Grounding bracket
6.02
Locking ring
4.35
Washer
6.03
Bearing cover NDE, inner
4.37
Terminal board
6.10
Rolling bearing
4.38
Spring lock washer
6.11
Spring band for end shield hub
4.39
Grounding stud
6.20
Bearing shield
