Assembly
5.5 Installing the machine
1MB..1/2/3/4 - shaft heights 63 ... 355
Operating Instructions, 06/2020, A5E44455710A
63
5.5 Installing the machine
5.5.1 Preconditions for smooth, vibration-free operation
Preconditions for smooth, vibration-free operation:
● Stable foundation design
● Precise alignment of the machine
● Correct balancing of parts to be fitted to the shaft end.
● Vibration values in compliance with ISO 10816-3
5.5.2 Aligning the machine to the driven machine and mounting
5.5.2.1 Horizontal types of construction with mounting feet
1. Refer to any instructions for aligning the driven machine and those of the coupling
manufacturer.
2. Align the machines with coupling output to the driven machine in such a manner that the
center lines of the shafts are parallel with no offset. This ensures that no additional forces
affect their bearings during operation.
3. For the vertical positioning (x→0) place thin shims under the machine feet. The number of
shims should be kept as low as possible, i.e. stack as few as possible. This also prevents
the machine being subjected to any stress/distortion. If available, use the existing tapped
holes for the forcing-off bolts to somewhat raise the machine.
4. When positioning the machine, ensure that a uniform axial gap (y→0) is maintained
around the coupling.
5. Fix the machine to the foundation. The choice of fixing elements depends on the
foundation and is the plant operator's responsibility.
When aligning, make allowance for the thermal expansion of the machine when the
temperature increases.
See also
Tightening torques for screw and bolt connections (Page 161)
