5.3 Mounting and installed the machine
1MB..1/2/3/4 - shaft heights 63 ... 355
60 Operating Instructions, 06/2020, A5E44455710A
5.3.3 Machines with type of construction IM B15, IM B9, IM V8 and IM V9
Types of construction without bearings on the drive side
These machines do not have their own bearing system for the machine shaft at the drive end
(DE). The machine shaft is accepted by the (hollow) shaft or coupling of the system or driven
machine.
● Using the centering edge, the machine is aligned with respect to enclosures, flanges or
driven machines.
● Note that the temperature of the motor and motor shaft increases during operation. The
thermal expansion of the machine shaft must be compensated by the customer by
applying suitable measures.
Use the spring washers provided to locate the NDE bearing without any play.
Material damage can occur if the following notes are not carefully observed:
• The IM B3 bearing shield with integrated distance ring mounted at the drive end (DE) is
only used transport lock. A warning label is attached to this bearing shield.
• The spacer ring is not a roller bearing.
• Remove the bearing shield and the spacer ring.
• Remove the transport lock before commissioning.
5.3.4 Foot mounting
Note
Only authorized retrofit partners must be employed to relocate the bolted on mounting feet at
the machine enclosure.
After attaching the mounting feet, you must note the following in order to avoid stressing and
deforming the machine.
● Ensure that the foot mounting surfaces are aligned in one plane and are parallel to the
machine shaft.
● Post-machine the foot mounting surfaces or use thin shims, for example.
● Professionally touch up damaged painted surfaces.
● Observe the information provided in Chapter Aligning and mounting (Page 61)
