Assembly
5.4 Alignment and fastening
1MB..1/2/3/4 - shaft heights 63 ... 355
62 Operating Instructions, 06/2020, A5E44455710A
● Smooth running
Preconditions for smooth, vibration-free operation:
– Stable foundation design free of any shock or vibration.
– A precisely aligned coupling.
– A well-balanced drive output element (coupling, belt pulleys, fans, ...)
Maintain the maximum permissible vibration values in operation according to ISO 10816-
3.
Avoid inadmissible vibration caused by imbalance, for example (drive output element),
external vibration or any resonance over the complete speed range.
It may be necessary to completely balance the machine with the drive output element or
the system resonance frequency must be shifted.
● Foot mounting/flange mounting
– Use the specified thread size laid down in EN 50347 when flanging the machine to a
foundation or a machine flange.
– Mount the machine at all the foot or flanged holes provided. The choice of fixing
elements depends on the foundation and is the plant operator's responsibility. Comply
with the required property classes for screwed connections and materials for fixing
elements.
– Select the correct screw length for IM B14 flanges.
– Ensure that the screw heads are in full contact with the flange surface. Use additional
flat washers (ISO 7093), especially for elongated foot mounting holes.
5.4.3 Flatness of the supporting surfaces for conventional motors
5.4.4 Machine frame mounting feet (special design)
Please note that when the terminal box is mounted at the NDE (option H08), dimension C
can deviate from EN 50347.
To comply with dimension C according to EN 50347, for machines with double or triple holes
at the NDE, use the appropriate screw bore.
