Siemens SIMOTICS XP User Manual

Description
3.3 Installation
1MB..1/2/3/4 - shaft heights 63 ... 355
30 Operating Instructions, 06/2020, A5E44455710A
For applications in Zone 21 (IEC/EN/GOST 60079-10-2, GB12476.3)
0158
II 2D Ex tb IIIC T... °C Db
0158
II 2D Ex tb IIIB
T... °C Db
0158
II 2D Ex tb IIIA T... °C Db
Ex tb IIIC T... °C Db X
Ex tb IIIB T... °C Db X
Ex tb IIIA T... °C Db X
CNEx
Ex tD A21 IP65 T... °C
For applications in Zone 22 (IEC/EN/GOST 60079-10-2, GB12476.3)
II 3D Ex tc IIIC T... °C Dc
II 3D Ex tc IIIB T... °C Dc
II 3D Ex tc IIIA T...
°C Dc
Ex tc IIIC T... °C Dc X
Ex tc IIIB T... °C Dc X
Ex tc IIIA T... °C Dc X
CNEx
Ex tD A22 IP55 T... °C
3.3.11 Terminal box
As an option, additional connecting terminals are available in the terminal box for monitoring
equipment. For larger machines, an additional terminal box can be optionally mounted. You
can see the number of available terminals in the circuit diagrams.
It is possible to turn the top side of a machine terminal box 4 x 90 degrees (if screwed on).
3.3.12 Paint finish
Paint finish
The machine is painted according to the instructions in your order.
Suitability test of the paint system for hazardous areas
For the paint systems ordered as standard on explosion-protected machines, verification of
the electrostatic suitability is available.
