Siemens SINUMERIK 808D Operating Instructions

Descriptions of the PLC subroutines
3.11 Subroutine 38 - MCP_Tool_Nr (display tool number on the MCP)
PLC Subroutines Manual
40 Operating Instructions, 12/2012, 6FC5397-2EP10-0BA0
Local variable definition
None
Assigned global variables
None
Example for calling subroutine 37
3.11 Subroutine 38 - MCP_Tool_Nr (display tool number on the MCP)
Purpose
Subroutine 38 is used to display active tool number (< 100) with the 7-segment LED on the
MCP. For a tool number ≥ 100, it displays "FF".
Local variable definition
None
Assigned global variables
None
Relevant PLC machine data
None
Example for calling subroutine 38
