PLC Subroutines Manual
Operating Instructions, 12/2012, 6FC5397-2EP10-0BA0
77
Use of user alarms in the PLC subroutines
4
Some user alarms are activated in a subroutine. In the case that such an alarm is generated,
you can search the following list for the subroutine wherein the alarm is activated.
Alarm No. Interface Address Alarm Description From SBR
700010 DB1600.DBX1.2 HHU is active SBR41: MINI_HHU
700011 DB1600.DBX1.3 Not able to lock tool in expected time
700012 DB1600.DBX1.4 Spindle in braking progress SBR42: SPINDLE
700013 DB1600.DBX1.5 Operation while chuck is not locked SBR56:
Lock_unlock_T
700014 DB1600.DBX1.6 Gear-change time out
700015 DB1600.DBX1.7 Gear level position error
SBR49:
GearChg1_Auto
700016 DB1600.DBX2.0 Drives not ready SBR33: EMG_STOP
700017 DB1600.DBX2.1 Operate chuck when spindle or part
program is running
SBR56:
Lock_unlock_T
700018 DB1600.DBX2.2 Cooling motor overload
700019 DB1600.DBX2.3 Coolant liquid position in low level
SBR44: COOLING
700020 DB1600.DBX2.4 Lubrication motor overload
700021 DB1600.DBX2.5 Lubricant liquid position in low level
SBR45: LUBRICAT
700022 DB1600.DBX2.6 Turret motor overload
700023 DB1600.DBX2.7 Programmed tool number > max. turret
on turret number
700024 DB1600.DBX3.0 Max. tool number setting error
700025 DB1600.DBX3.1 No position signals from turret
700026 DB1600.DBX3.2 Not able to find expected tool in monitor
time
SBR51:
Turret1_HED_T
SBR52:
Turret2_BIN_T
SBR53:
Turret3_CODE_T
700027 DB1600.DBX3.3 Approach reference point again after
rotation monitoring
SBR40: AXIS_CTL
700028 DB1600.DBX3.4 Tool is not locked SBR53:
Turret3_CODE_T
700029 DB1600.DBX3.5 Reminding information for 1st service
plan
700030 DB1600.DBX3.6 Alarm for 1st service plan
SBR48: ServPlan
700031 DB1600.DBX3.7 Magazine not in spindle position or
original position
SBR60: Disk_MGZ_M
700032 DB1600.DBX4.0 Magazine in spindle position and
original position
SBR60: Disk_MGZ_M
700033 DB1600.DBX4.1 Magazine turn key when magazine or
spindle not ready
SBR60: Disk_MGZ_M
700034 DB1600.DBX4.2 Block search, tool in spindle <>
programmed tool
SBR60: Disk_MGZ_M
