Singer QUANTUM STYLIST 9960 User Manual

14 Singer Quantum Stylist
TM
9960
10. The gap between the needle and the hook
Check
2. Remove needle plate and bobbin case.
3. Turn the hand wheel and check so the needle clearance to shuttle at both left and right side of needle posi-
tions are within 0.05 to 0.15 mm.
Adjustment
1. Remove needle plate, bobbin case and face cover.
2. Set machine
3. Turn the screw (A) on the back of the machine.
4. When turning screw (A) until the correct needle clearance is obtained.
- To decrease clearance, move the needle bar unit (B) to the front (D - direction).
- To increase clearance , move the needle bar unit to the back (C - direction) .
5. Re-check to see so the needle clearance to shuttle is within 0.05 to 0.15 mm.
A
A
C
D

Singer QUANTUM STYLIST 9960 Specifications

General

Stitch Applications	600
Built-In Needle Threader	Yes
Maximum Sewing Speed	850 stitches per minute
Automatic Thread Cutter	Yes
Drop Feed	Yes
Extension Table	Yes
Type	Computerized
LCD Screen	Yes
Bobbin System	Top drop-in
Number of Buttonholes	13
Lettering Fonts	5
Buttonhole Styles	13
Stitch Width	7mm
Stitch Length	5mm
USB Port	No
Voltage	110V
Warranty	25-year limited warranty
