Singer Quantum Stylist
TM
9960 29
Removing the covers
The exterior parts should be removed in sequence as follo-
wings.
CAUTION:
Always disconnect the main lead plug from electrical outlet
when removing the exterior parts.
A. Light Cover
1. Loosen the light cover set screw (a).
2. Pull the bottom hook (b) toward you and open the light
cover to the left.
Hook (b, c) will come off.
B. Top Cover
1. Open the top cover about 1/3.
Push the right side of top cover to come off the hinge (a).
2. Slide the top cover to the right and come off the hinge
a
c
b
a
b
To Next Page
