Singer Quantum Stylist

9960 21

17. Height of bobbin thread pullout arm

Check

1. This arm moves to three different positions (High, Middle, and Low) by turning the hand wheel.

When the arm is at the middle height, the arm should be 0.2-0.3 mm lower than the highest point of the

bobbin case (a).

Adjustment

1. Remove the needle plate, base, front and rear cover.

2. To get excess to the setting screw, push the pin (b) of thread cutter solenoid lightly, and turn the hand

wheel toward you, this will insert the cam follower pin (c) into the thread cutter cam.

3. Turning the hand wheel toward you more degrees, until that the movable knife (d) be in a position so it

does not block adjust hole (e). (At this time, the arm will be set at the highest position.)

4. Turn the adjust screw which is located deep inside of the hole (e) by 1.5 mm hex wrench.

- Turn clockwise: The arm comes higher.

- Turn counter-clockwise: The arm comes lower.

5. Turn the hand wheel toward you 2-3 turns.

6. Re check the height of the arm in its middle position is 0.2 to -0.3 mm lower than the highest point of

the bobbin case (a).
