Singer QUANTUM STYLIST 9960 User Manual

20 Singer Quantum Stylist
TM
9960
16. Tension of motor and pulley belt
Check
1. Remove the covers.
2 Check tension of pulley belt by pushing it lightly (about 300 g) with your fi nger and then it should fl ex
about 5-6 mm.
Adjustment
1. Remove the covers.
2. Loosen lightly the two set screws (a) and (b).
3. Move motor up or down until the correct belt tension is obtained.
4. Tighten the two set screws (a) and (b).
a
b

Singer QUANTUM STYLIST 9960 Specifications

General

Stitch Applications	600
Built-In Needle Threader	Yes
Maximum Sewing Speed	850 stitches per minute
Automatic Thread Cutter	Yes
Drop Feed	Yes
Extension Table	Yes
Type	Computerized
LCD Screen	Yes
Bobbin System	Top drop-in
Number of Buttonholes	13
Lettering Fonts	5
Buttonhole Styles	13
Stitch Width	7mm
Stitch Length	5mm
USB Port	No
Voltage	110V
Warranty	25-year limited warranty
