9.1.2 HRR012/018/024/030-W-20-(DMT)U(Y)
Table 9-2 Specifications [HRR012/018/024/030-W-20-(DMT)U]
Model
HRR012-W
-20-(DMT)U(Y)
HRR018-W
-20-(DMT)U(Y)
HRR024-W
-20-(DMT)U(Y)
HRR030-W
-20-(DMT)U(Y)
Cooling method
Water-Cooled refrigerated type
Refrigerant
R410A(HFC)
Quantity of refrigerant
Kg
0.25
0.25
0.4
0.4
Control method
PID control
Ambient temperature andhumidity and altitude
1 15
Temperature:5 to 40℃、Humidity:30 to 70%、Altitude: Less than 3000m
Circulating
fluid
system
Tap water, Ethylene glycol aqueous
solution 15%
Tap water, Ethylene glycol aqueous solution 15%
Operating temperature
range

1
℃
10 to 35
Cooling capacity (50/60Hz)

3
W
1000/1200
1600/1800
2000/2400
2500/3000
Heating capacity
(50/60Hz)

4
W
450/500
550/700
Temperature stability 

5
℃
±0.1
Pump capacity (50/60Hz)

6
L/min
0.13（at 7L/min）/0.18(at 7L/min)
For option -T：0.42（at 10L/min）/0.4(at 14L/min）
For option -MT：0.32（at 10L/min）/0.32(at 14L/min）
Rated fiow (50/60Hz) 

7
L/min
7 / 7 For option -T,-MT：10/14
Flowdisplay range
L/min
3 to 16
Electric conductivity
display range
µS/cm
2 to 48(For option -DM)
Electric conductivity
setting range
µS/cm
5 to 45(For option -DM)
Particle filter nominal
filtration rating
µm
5
Bypass valve
Installed
Tank capacity
L
Approx.4
Fluid outlet , fluid return port port
size
Rc1/2
Drain port size
Rc1/4,With cap
Leakage protection
Drain pan structure (With water leakage detector )
Fluid contact part material
Stainless steel, Copper brazing (Heat exchanger)

12
,Brass

18
,SiC,
Aluminum oxide ceramic,Carbon,PP,PE,POM,PA,FKM,EPDM,PVC,
PPS,AS,fluoropolymer

13
,Ion exchange resin

13
Facility water
outlet system
Temperature range
℃
5 to 40
Pressure range
MPa
0.3 to 0.5
Required flow
(50/60Hz)

14
L/min
8
12
14
15
Facility water
pressure difference
MPa
0.3 more
Port size
Rc3/8
Fluid contact material
Stainless steel, Copper brazing,Bronze, Synthetic rubber
Electrical
system
Power supply
1-phase AC200 to 230V 50/60Hz Allowable voltage range 10%

16
Circuit protector
A
10 (For option -T,-MT：15)
Applicable earth leakage breaker

8
Rated current：10A (For option -T,-MT：15A)
Sensitivity current：30mA
Cable Qty x size(Incuding ground)

16
3core×14AWG(3 core×2.0m ㎡)
Rated operating current
(50/60Hz)

3
A
3.2/3.6
3.3/3.6
4.9/5.1
4.9/5.2
For option -T,-MT
4.3/5.8
4.4/5.8
6.0/7.3
6.0/7.4
Rated power consumption
(50/60Hz)

Kw
(kVA)
0.6/0.7
(0.7/0.7)
0.6/0.7
(0.7/0.7)
0.8/1.0
(1.0/1.0)
0.8/1.0
(1.0/1.0)
For option -T,-MT
0.9/1.1
(0.9/1.2)
0.9/1.1
(0.9/1.2)
1.1/1.2
(1.4/1.4)
1.1/1.2
(1.4/1.4)
Communication function
Contact input / output, Serial RS-485 / RS-232C
Noise level (50/60Hz)

9
dB
59/60
59/60
61/64
61/64
Dimensions 

10
mm
W483xD550xH310
W483xD550xH399
Accessory
power supply connector,Maintenance handle for particle filter,
Operation manual,Particle filter element
Weight 

11
kg
41
45
1: Use the product in conditions where freezing will not occur. Consult with SMC if using in a season or region where
the ambient temperature will fall below zero.
2: If tap water is used, use water which satisfies the standard of The Japan Refrigeration And Air Conditioning
Industry Association (JRA GL-02-1994/Cooling water system –circulation type - make-up water).
