SMC Networks HRR012-A*-20 Series User Manual

HRX-OM-W002-A
Chapter 5 Display and Setting of Various Functions
5.3 List of parameters HRR Series
5-10
5.3.7 Communication setting menu
Table 5.3-7 Communication setting menu Parameter list
1：OFF/RUN/RMT/EXT.C/RDY/T.OUT/FLT/WRN/MENT/
Selectable from ALM/SW1/SW2/A.SEL/M.SEL
Initial value Select/setting range
TOP
screen
－ COMM － MENU
No.1
screen
Serial protocol ASC ASC/RTU PROT
No.2
screen
Communication specification 485 485/232C TYPE
No.3
screen
RS-485 terminal unit OFF OFF/ON TERM
No.4
screen
Slave address 1 1 to 32 SLV ⇒ ADDR
No.5
screen
Communication speed（bps） 19.2 9.6/19.2 SPEED
No.6
screen
Contact input signal 1 function OFF OFF/RN.ST/RUN/SW D.IN1 ⇒ SEL
No.7
screen
Contact input signal 1 type ALT ALT/MT D.IN1 ⇒ SW ⇒ TYPE
No.8
screen
Contact input signal 1 operation
A A/B D.IN1 ⇒ CON ⇒ TYPE
No.9
screen
Contact input signal 2 function OFF OFF/STOP/SW D.IN2 ⇒ SEL
No.10
screen
Contact input signal 2 type ALT ALT/MT D.IN2 ⇒ SW ⇒ TYPE
No.11
screen
Contact input signal 2 operation
A A/B D.IN2 ⇒ CON ⇒ TYPE
No.12
screen
Contact output signal 1 function RUN 1 D.OUT1 ⇒ SEL
No.13
screen
Contact output ignal 1 operation A A/B D.OUT1 ⇒ TYPE
No.14
screen
Contact output signal 1 alarm AL.01 AL.01 to AL.32 D.OUT1 ⇒ ALARM ⇒ CODE
No.15
screen
Contact output signal 1 maintenance
MT.01 MT.01 to MT.05 D.OUT1⇒ MANT ⇒ CODE
No.16
screen
Contact output signal 2 function RMT 1 D.OUT2 ⇒ SEL
No.17
screen
Contact output signal 2 operation A A/B D.OUT2 ⇒ TYPE
No.18
scree
Contact output signal 2 alarm AL.01 AL.01 to AL.32 D.OUT2 ⇒ ALARM ⇒ CODE
No.19
screen
Contact output signal 2 maintenance
MT.01 MT.01 to MT.05 D.OUT2 ⇒ MANT ⇒ CODE
No.20
screen
Contact output signal 3 function ALM  1 D.OUT3 ⇒ SEL
No.21
screen
Contact output signal 3 operation B A/B D.OUT3 ⇒ TYPE
No.22
screen
Contact output signal 3 alarm AL.01 AL.01 to AL.32 D.OUT3 ⇒ ALARM ⇒ CODE
No.23
screen
Contact output signal 3 maintenance
MT.01 MT.01 to MT.05 D.OUT3 ⇒ MANT ⇒ CODE
5.5.5
ScreenNo.
Item
Display unit
Reference
page
Upper stage（White）
Lower stage
（Green）
