Sony HCD-DX375 - Tray; MOTOR Board M761 (LD;ST Motor); M762 (BU U;D Motor)

22
HCD-DX375
3-11. TRAY
3-12. MOTOR BOARD M761 (LD/ST MOTOR), M762 (BU U/D MOTOR)
1 screw
(+BTTP 2.6)
2 bracket
3 screw
(+BTTP 2.6)
4 MOTOR board
5 Remove soldering from the two points.
6 M761 (LD/ST MOTOR)
7 Remove soldering from the two points.
8 M762 (BU U/D MOTOR)
1 two screws
(+BTTP 2.6)
2 two screws
(+BTTP 2.6)
3 bracket
4
5
tray
