HCD-S550/S880
13
3-8. POWER BOARD
3-9. AMP BOARD
3
connector
(CN902)
4
four screws
(BVTP3
×
8)
6
power sheet
5
7
power boar
d
1
connector
(CN904)
2
connector
(CN903)
2
connector
(CN302)
5
two screws
(BVTP3
×
8)
4
four screws
(BVTP3
×
8)
1
two wires (flat type)
(CN301, 305)
3
connector
(CN904)
6
AMP board
