Sony HCD-S550 Service Manual

HCD-S550/S880
17
3-16. PULLEY (SPT) ASSY
3-17. BELT (CK), MOTOR (CK) ASSY (M751)
1 busing (CDM72)
2 belt (CK)
3 pulley (CKG)
7 motor (CK) ass
y
(M751)
6 CK motor board
5 two screws
(BTP2.6
× 6)
4 two solders
2 pulley (SPT) assy
3 gear (S2)
4 torsion spring (S)
5 gear (SPT)
6 gear (KT)
hole
shaft
(pulley (SPT) assy
1 Rotate the pulley (SPT) assy to fit position
of the shaft to the hole of the chassis.
