HCD-S550/S880
6161
7-34. SCHEMATIC DIAGRAM – CONTROL Section –
CNP813CN820
C801
C800
R864
R809
R873
S821 S822 S823 S805 S803
S825
CNP808
R860R849R844R837
R800 R801 R802 R803
S800
S806
S804 S802 S801S824
3P3P
0.01
0.01
4.7k
220
220
6P
1k680470330
330 470 680 1k
GND
ENA
GND
ENB
ROTARY
ENCODER
VOLUME
DISPLAY NEXTPREV
PRESET
+ -
SOUND
-
FIELD
+
BAND
FUNCTION
(Page 59)
