Sony HCD-S550 Service Manual

HCD-S550/S880
15
3-12. HOLDER (AT) ASSY, RETAINER (CHASSIS) BLOCK
3-13. BELT (L2)
2 three screws
(BTP2.6
× 8)
1 tension spring
(S5)
4 four screws
(BTP2.6
× 6)
3 holder (AT) assy
5 retainer (chassis) bloc
k
1 two gears
(S1)
2 belt (L2)
3 pulley (LDG)
