24
HCD-S500/S800
SECTION 6
DIAGRAMS
CIRCUIT BOARDS LOCATION
PW-1030 board
FU-1030 board
HP-1030 board
FP-1030 board
Loading board
RF-240 board
DVD board
TUNER UNI
T
I/O board
SW (B)-1030 board
SW (A)-1030 board
AMP board
DDCON-1030 board
RR-1030 board
Power board
