HCD-S500/S800
6-5. PRINTED WIRING BOARD – DVD SECTION (2/2) –
IC006
IC001 IC003
IC502
IC504
IC505
IC102
IC604
IC902
IC603
IC610
IC608
IC601
IC602
IC600 IC605
IC501
IC304
IC303
IC401
IC108
IC1007
IC804
IC803
Ref. No. Location
D900 D-6
D902 E-6
IC001 A-2
IC003 A-2
IC006 A-1
IC102 C-2
IC107 C-5
IC108 C-5
IC303 B-4
IC304 B-3
IC401 B-5
IC501 B-3
IC504 B-2
IC505 B-2
IC600 E-1
IC601 E-1
IC602 E-2
IC603 E-1
IC604 D-2
IC605 E-3
IC608 E-2
IC610 E-2
IC803 D-4
IC804 D-5
IC902 D-3
Q001 A-1
Q002 A-1
Q900 E-6
Q901 E-6
Q902 D-5
Q906 D-6
Q907 D-6
• Semiconductor
Location
