SECTION 8
ELECTRICAL PARTS LIST
75
HCD-S500/S800
Note:
• Due to standardization, replacements in the parts
list may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
AR : Argentina model
AUS : Australian model
CND : Canadian model
EA : Saudi Arabia model
E12 : 220-240V AC area in E model
E32 : 110-240V AC area in E model
HK : Hong Kong model
KR : Korean model
MX : Mexican model
MY : Malaysia model
SP : Singapole model
TW : Taiwan model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
A-4726-398-A AMP BOARD, COMPLETE
(S500:US,CND,MX/S800,MX)
********************
A-4726-586-A AMP BOARD, COMPLETE
(S500:CIS/S800:AEP,CIS,UK,KR)
********************
A-4726-819-A AMP BOARD, COMPLETE (S500:AEP,UK,KR)
********************
A-4726-895-A AMP BOARD, COMPLETE (S500:TW,AUS)
********************
A-4726-903-A AMP BOARD, COMPLETE
********************
(S500:E12,E32,EA,MY,SP,HK,AR)
A-4727-397-A AMP BOARD, COMPLETE (S800:EA,HK)
********************
A-4727-405-A AMP BOARD, COMPLETE (S800:TW,AUS)
********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C300 1-126-953-11 ELECT 2200uF 20.00% 35V
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C300 1-126-973-11 ELECT 2200uF 20.00% 50V
(EXCEPT S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C301 1-126-965-11 ELECT 22uF 20.00% 50V
C302 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C303 1-136-157-00 MYLAR 0.022uF 5.00% 50V
C304 1-136-157-00 MYLAR 0.022uF 5.00% 50V
C305 1-163-021-11 CERAMIC CHIP 0.01uF 10.00% 50V
(EXCEPT S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C305 1-136-165-00 MYLAR 0.1uF 5.00% 50V
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C306 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C307 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
(EXCEPT S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C307 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C308 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C309 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C310 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C311 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C312 1-104-665-11 ELECT 100uF 20.00% 10V
C313 1-163-021-11 CERAMIC CHIP 0.01uF 10.00% 50V
(EXCEPT S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C313 1-136-165-00 MYLAR 0.1uF 5.00% 50V
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C316 1-163-021-11 CERAMIC CHIP 0.01uF 10.00% 50V
C317 1-126-948-11 ELECT 100uF 20.00% 35V
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C317 1-126-968-11 ELECT 100uF 20.00% 50V
(EXCEPT S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C318 1-104-665-11 ELECT 100uF 20.00% 10V
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C318 1-136-165-00 MYLAR 0.1uF 5.00% 50V
(EXCEPT S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C319 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C319 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EXCEPT S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C320 1-104-665-11 ELECT 100uF 20.00% 10V
C323 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C324 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C325 1-104-665-11 ELECT 100uF 20.00% 10V
C326 1-126-947-11 ELECT 47uF 20.00% 10V
C327 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C328 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C328 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EXCEPT S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C329 1-126-934-11 ELECT 220uF 20.00% 10V
C330 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C331 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C331 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EXCEPT S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C332 1-136-157-00 MYLAR 0.022uF 5.00% 50V
C333 1-136-157-00 MYLAR 0.022uF 5.00% 50V
C334 1-136-165-00 MYLAR 0.1uF 5.00% 50V
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C334 1-163-021-11 CERAMIC CHIP 0.01uF 10.00% 50V
(EXCEPT S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C335 1-136-165-00 MYLAR 0.1uF 5.00% 50V
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C335 1-163-021-11 CERAMIC CHIP 0.01uF 10.00% 50V
(EXCEPT S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C336 1-104-665-11 ELECT 100uF 20.00% 10V
C337 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C337 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EXCEPT S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C341 1-163-021-11 CERAMIC CHIP 0.01uF 10.00% 50V
C342 1-126-948-11 ELECT 100uF 20.00% 35V
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C342 1-126-968-11 ELECT 100uF 20.00% 50V
(EXCEPT S500:US,CND,AEP,CIS,UK,MX,KR/S800)
C343 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
AMP
