On-Screen Indications
21
Overview
6. Media remaining indication [M] (page 34)
7. Zoom position indication [M] (page 49)
8. TLCS mode indication [M][D] (page 105)
9. Steady Shot indication [M][D] (page 54)
10. Focus mode indication [M] ( [D] only in MF
mode) (page 51)
11. White balance mode and color
temperature indications [M][D] (page 41)
12. Picture profile indication [M][D] (page 73)
13. ND filter indication [M] (page 40)
14. Iris position indication [M][D] (page 48)
15. Gain indication [M][D] (page 45)
16. Shutter mode/shutter speed indication
[M][D] (page 46)
17. Audio level meters [M] (page 58)
18. Histogram indication [M][A]
19. Fader indication [M] (page 71)
20. Video level cautioning indication [M]
If the video level is too high or too low, a caution
is generated showing the appropriate ND filter
number.
21. Depth-of-Field indication [M][A]
22. Brightness level indication [M][A]
23. Special recording mode indication [M] ([D]
only in Slow & Quick Motion Standby)
24. Video Format indication [M] (page 39)
The settings of the items named with a suffix [D]
can be changed using the Direct menu on the
screen.
Select “All,” “Part,” or “Off” for Direct Menu
using “Direct Menu” (page 112) of the OTHERS
menu.
When the Direct mode is set to “Part,” the
operation is limited depending on the GAIN,
SHUTTER, or WHITE BAL switch setting.
When the Direct mode is set to “All,” the GAIN,
SHUTTER, and WHITE BAL switches are
disabled.
Note
When the indicator of the FULL AUTO button is
lit, the Direct Menu operation is disabled for the
functions that are forcibly set to the automatic
mode in Full Auto mode (page 37).
To operate the Direct menu
Use the joystick on the handle or the jog dial on
the rear control panel.
1 Press the joystick or the jog dial.
If “Direct Menu” is set to “All” or “Part,” the
cursor is displayed on one of the items for
which the Direct menu operation is
permitted.
Example: TLCS mode indication
2 Tilt the joystick or rotate the jog dial to
set the cursor to the item to be operated
then press the joystick or the jog dial.
Backlight mode
Standard mode
Spotlight mode
Frame Rec Frame Rec mode
Interval Rec Interval Rec mode
S&Q Motion
xx/xx fps
Slow & Quick Motion mode
Direct Menu Operation
