132
US
Reference sections
If the buttons on the receiver or the remote
control do not work due to a malfunction of the
receiver, reboot the receiver.
Hold down ?/1 for 10 seconds.
When the lamp above ?/1 flashes in green, the
reboot starts.
Refer to the following web site for details of
the latest information on the receiver.
http://www.sony.com/essupport
Specifications
AUDIO POWER
SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
With 8 ohm loads, both channels driven, from
20 – 20,000 Hz; rated 100 watts per channel
minimum RMS power, with no more than
0.09% total harmonic distortion from 250
milliwatts to rated output.
Amplifier section
POWER OUTPUT
1) 2)
Rated Power Output at Stereo Mode
(8 ohms 20 Hz – 20 kHz,
THD 0.09%):
100 W + 100 W
Reference Power Output
(8 ohms 1 kHz, THD 0.7%)
FRONT:
110 W + 110 W
CENTER: 110 W
SURROUND:
110 W + 110 W
SURROUND BACK:
110 W + 110 W
1)
Measured under the following conditions:
Power requirements: 120 V AC, 60 Hz
2)
Depending on the sound field settings and the
source, there may be no sound output.
Frequency response
3)
Inputs (Analog)
3)
When “2ch Analog Direct” is being used.
Clearing the memory
To clear See
All memorized settings page 89
Rebooting the receiver
About support information
SA-CD/CD, TV,
VIDEO 1/2, SAT/CATV
10 Hz – 100 kHz
± 3 dB
SA-CD/CD, TV,
VIDEO 1/2, SAT/CATV
Sensitivity: 150 mV
Impedance: 50 kohms
S/N
3)
: 105 dB (A,
20 kHz LPF. 500 mV)
