This receiver is equipped with a function for converting video signals.
• Composite video signals can be output as HDMI video and component video signals.
• Component video signals can be output as HDMI video and video signals.
As the factory default setting, video signals input from the connected equipment are output to the
HDMI OUT or MONITOR OUT jacks as shown in the table below.
We recommend you set the video conversion function to match the resolution of the monitor you
are using.
For details on the video converting function, see “Video Settings” (page 100).
a : Video signals are output.
– : Video signals are not output.
* When “Auto” is selected in “Resolution,” up to 4K up-scaling is enabled.
To enjoy 4K signals, a 4K-compatible monitor must be connected.
** Video signals may not be output, depending on the setting in “Resolution” (page 100).
Note on converting video
signals
Video signals for which the resolution has
been converted may not be output from the
COMPONENT VIDEO MONITOR OUT
jacks or the HDMI OUT jacks simultaneously.
If you connect equipment to both the
COMPONENT VIDEO MONITOR OUT
jacks and the HDMI OUT jacks, priority is
given to the output from the HDMI OUT jacks.
Note on Zone 2 HDMI video
output
Only HDMI IN input signals can be output
through the HDMI ZONE 2 OUT jack.
To display Closed Caption
Set “Resolution” to “Direct” in the Video
Settings menu when receiving a signal that
supports Closed Captions.
Use the same kind of cords for the input/output
signals.
To connect a recording device
When recording, connect the recording device
to the VIDEO OUT jacks of the receiver.
Connect cords for input and output signals to
the same type of jack, as VIDEO OUT jacks
do not have an up-conversion function.
The HDMI OUT and the MONITOR OUT
jacks cannot be used for recording.
Function for conversion of video signals
HDMI OUT A/B
(up to 4K)
COMPONENT
VIDEO MONITOR
OUT
(up to 1080i)
MONITOR VIDEO
OUT
VIDEO 1 OUT
HDMI IN a –––
VIDEO IN a* a** a** a
COMPONENT VIDEO IN a * a** a** –
INPUT jack
OUTPUT jack

Sony STR-DA2800ES Specifications

General

Bi-amping	Yes
Night mode	No
Sample rate	192 kHz
Product color	Black
Connector contacts plating	Nickel
Case or master carton weight	15 kg
Power consumption (standby)	0.5 W
Power consumption (typical)	290 W
Dimensions (WxDxH)	500 x 258 x 487 mm
Total Harmonic Distortion (THD)	0.09 %

Weight and Dimensions

Weight	12400 g
