Rear panel
1 2
8 76 5 34
BD
IN
DIGITAL
COMPONENT VIDEO
DMPORT
AUTO CAL
MIC
SA-CD / CD
DC5V 0.7A MAX
OPTICAL
COAXIAL
SAT
IN
SAT IN
IN
TV
IN
SAT
AUDIO
IN
DVD IN MONITOR
OUT
DVD
IN
Y
P
B/ C B
P R/ C R
VIDEO
IN
VIDEO
AUDIO
OUT
AUDIO
OUT
VIDEO
OUT
AUDIO
IN
VIDEO
IN
DVD
VIDEO
IN
MONITOR
SUBWOOFER
VIDEO
OUT
AM
SURROUNDCENTER
L
L
R
R
SPEAKERS
FRONT
R
L
ANTENNA
SAT IN DVD IN BD IN OUT
HDMI
CONNECT TO
DIGITAL
INPUT
FOR
AUDIO
A DIGITAL INPUT/OUTPUT section
OPTICAL
IN jacks
Connects to a DVD
player, etc. The
COAXIAL jack
provides a better
sound quality (page
18, 20, 21).
COAXIAL IN
jack
HDMI IN/
OUT* jacks
Connects to a
satellite tuner,
DVD player or a
Blu-ray disc player.
The image and the
sound are output to
a TV (page 18).
B ANTENNA section
FM
ANTENNA
jack
Connects to the
supplied FM wire
antenna (aerial)
(page 22).
AM
ANTENNA
terminals
Connects to the
supplied AM loop
antenna (aerial)
(page 22).
C SPEAKERS section
Connects to the
speakers (page 14).
D VIDEO/AUDIO INPUT/OUTPUT
section
AUDIO IN/
OUT jacks
Connects to a VCR,
DVD player, etc.
(page 15–22).
VIDEO IN/
OUT* jacks
White (L)
Red (R)
Yellow
continued

Sony STR-DH500 Specifications

General

Equalizer	Yes
Product color	Black
Audio decoders	DTS
Impedance	8 Ω
RMS rated power	500 W
Audio output channels	5.1 channels
Total Harmonic Distortion (THD)	1 %
Supported radio bands	AM, FM
Headphone outputs	1
Dimensions (WxDxH)	430 x 157.5 x 322 mm
Power requirements	120 V, 60 Hz
HDMI ports quantity	4
I/O ports	2 x Anten. 1 x Coax. - in 3 x Compon. - in 1 x Compon. - out 2 x HD Compon. - in 1 x HD Compon. - out 2 x Compos. - in 1 x Compos. - out 1 x DM 3 x HDMI - in 1 x HDMI - out 2 x Opt. - in 1 x Sub. - out
Power consumption (standby)	0.3 W

Weight and Dimensions

Weight	7400 g
