STR-ZA5000ES
7-6. HUB BOARD SECTION
251
ANALOG board section
not supplied
not supplied
#1
#1
#1
#1
#1
#1
254
254
254
253
252
#1
#1
#1
#1
#1
PU1
#1
#1
#1
FFC4
not
supplied
not
supplied
not
supplied
not supplied
not
supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
(GND board)
#1
#1
#1
#1
#1
#1
#1
255
254
– Rear view –
251
#1
ws
ws
251 4-249-675-02 +BV SUMITITE S 4X6 ROUND
252 4-534-632-01 INDICATOR (REAR)
253 4-534-633-01 COVER (INDICATOR-REAR)
* 254 3-703-150-11 CLAMP
255 A-2087-839-A HUB BOARD, COMPLETE (SV)
256 4-974-510-11 SCREW (+BV 3X8 CU)
FFC4 1-921-415-21 FFC 11P (130)
0 PU1 1-474-585-11 POWER UNIT
#1 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
