91
STR-ZA5000ES
7-11. SPTM BOARD SECTION
502
501
501
501
501
501
501
501
501
501
#1
#1
#1
not supplied
(HEIGHT_SPTM board)
not supplied
chassis section
– Rear view –
501
501 3-704-515-51 SCREW (BV/RING)
502 A-2082-791-A SPTM BOARD, COMPLETE
#1 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
