• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
SECTION 3
DISASSEMBLY
3-2. CABINET LOWER,
TELESCOPIC ANTENNA (ANT1)
(Page 8)
3-3. MAIN CHASSIS SECTION
(Page 9)
3-4. AUDIO BOARD,
BATTERY BOARD
(Page 9)
3-5. TUNER BOARD,
CONTROL BOARD
(Page 10)
3-6. CDMP3 BOARD
(Page 11)
3-7. OPTICAL PICK-UP
SECTION
(Page 11)
3-8. SLED MOTOR ASSY
(780CP) (M702)
(Page 12)
3-9. OPTICAL PICK-UP
(KSS-900A)
(Page 12)
3-10.CABINET FRONT SECTION
(Page 13)
3-11.SPEAKER (10cm) (L) (SP1),
SPEAKER (10cm) R) (SP2)
(Page 13)
3-12.LID CD
(Page 14)
SET

Sony ZS-X3CP Specifications

Audio Specifications

digital filter	8X Oversampling
digital to analog conversion	1 Bit
cd frequency response	20-20000Hz, +1, -2dB

Tuner Specifications

tuner frequency range AM	530-1710kHz
tuner frequency range FM	87.6-108MHz
antenna system AM	Built-in Ferrite Bar Antenna
antenna system FM	Telescopic Antenna

Speaker Specifications

speakers	4" (10cm) x 2
outputs	Headphone (stereo mini jack)

Power

power requirements batteries	“D” x 6 Batteries (optional)
power requirements AC	AC 120V, 60Hz
inputs	DC In

Weight and Dimensions

dimensions	16 [7]⁄8" x 6 [3]⁄4" x 11 [1]⁄4" (430 x 172 x 287.5mm)
weight	8 lbs 8 [2]⁄3 oz (3.8kg) w/batteries
