Edition
2016
Workshop Manual
PARK 120 - PARK 220
Chapter
7 Electrical system
Page
61
7.4.2 Replacing the fuse
Attention!
The current strengths given in this section are the maximum values of the fuse
that may be installed. If a higher current fuse is installed there is a risk of re
damage to the machine.
The machine is equipped with one fuse.
The fuse is located under the machine engine cover, see picture below. To replace or
check the fuse the engine cover has to be removed.
2.1.1 for a description of the disassembly.
Designation U.M. PARK 120 PARK 220
Main fuse A 20
20 A
