Legacy U.S.A. (E)
8-18
J
T
owing eyelet
CAUTION
D
Never use the tie-down eyelet closest to the muffler under the
vehicle for towing purposes.
D
Do not apply excessive lateral load to the towing eyelets.
OM-H2744
HB0276
T
owing
eyelet
T
owing eyelet
HB0075
T
ie-down eyelet:
Never use the tie-down
eyelet for towing purpose.
The towing eyelets should be used only in an emergency (e.g., to fr
ee a
stuck vehicle fr
om mud, sand or snow).
295
297
