Legacy U.S.A. (E)
1
0
Maintenance and service
10-43
–
CONTINUED
–
OM-H0231
New tread Worn
tread
OM-H0230
T
read wear indicator
A tir
e should be r
eplaced when the tread wear indicator appears as
a
solid band acr
oss the tread. The indicators appear when the r
emaining
tr
ead has been wor
n to 0.063 in (1.6 mm) or less.
J
Wheel covers
B
Removing the wheel cover
OM-H2454
Inser
t the wheel nut wrench into the notch pr
ovided, and pr
y the
wheel cover of
f.
