Legacy U.S.A. (E)
1
1
Specifications
1
1-9
–
CONTINUED
–
J
Fuse panel located in the engine compartment
OM-H0254
Fuse panel
Fuse rating
Circuit
25
20A
D
Cooling fan
26
10A
D
Air conditioner
27
Spar
e
(Not used)
28
Spar
e
(Not used)
29
Spar
e
(Not used)
30
15A
D
Hazar
d warning flasher
31
20A
D
Lighting switch
32
15A
D
Headlight (left side)
33
15A
D
Clock
D
Interior light
34
15A
D
Headlight (right side)
