Legacy U.S.A. (E)
1
1-8
J
Fuse panel behind the instrument panel lower cover
HB0217
Fuse panel
Fuse rating
Circuit
22
15A*
1
or
20A*
2
D
Accessor
y power socket
D
Seat heater
23
Empty
24
Empty
*
1
: For vehicle with either accessory power socket (in luggage compar
tment) or seat
heater
*
2
: For vehicle with both seat heater and accessory power socket.
