Engine compartment overview
1 Manual transmission oil level
gauge (MT) (page 10-21) or
Differential gear oil level
gauge (AT) (page 10-24)
2 Automatic transmission fluid
level gauge (page 10-23)
3 Clutch fluid reservoir (2.5L, MT)
(page 10-31)
4 Brake fluid reservoir
(page 10-29)
5 Fuel filter
6 Windshield washer tank
(page 10-33)
7 Fuse box (page 10-45)
8 Battery (page 10-32)
9 Engine oil filler cap
(page 10-7)
Q Radiator cap (page 10-12)
W Engine coolant reservoir
(page 10-12)
E Engine oil level gauge
(page 10-7)
R Power steering fluid reservoir
(page 10-27)
T Air vent plug (Page 10-14)
Y Air cleaner (page 10-17)
HB0351
1243567
9
8EWTRY
