5 Electrical Connection User Manual
figure 5-1 Terminal Description(For a multi-core cable)
figure 5-2 Terminal Description(For four single-core cables)
* The image shown here is for reference only. The actual product received may differ.
Item Terminal Mark Note
A PV terminals + / - MC4 PV connector
34
