3-98 ENGINE
PAIR (AIR SUPPLY) SYSTEM
PAIR SYSTEM REMOVAL
• Remove the fuel tank. ($4-3)
• Disconnect all of the PAIR valve hoses.
1 Vacuum hose
2 Air cleaner hose
3 PAIR hose No. 1
4 PAIR hose No. 2
5 PAIR hose No. 3
6 PAIR hose No. 4
• Remove the PAIR valve.
• Remove the PAIR pipes from each cylinder.
PAIR SYSTEM INSTALLATION
Installation is in the reverse order of removal. ($3-100)
• Tighten the PAIR valve mounting bolt to the specified torque.
% PAIR valve mounting bolt: 10 N
.
m (1.0 kgf
.
m, 7.0 lb-ft)
• Tighten the PAIR pipe mounting nuts to the specified torque.
% PAIR pipe mounting nut: 10 N
.
m (1.0 kgf
.
m, 7.0 lb-ft)
!
Use a new gasket to prevent exhaust gas leakage.

Suzuki GSF1200S 2001 Specifications

General

Displacement	1157 cc
Compression Ratio	9.5:1
Ignition	Electronic ignition (Transistorized)
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Front Brakes	Dual disc
Rear Brakes	Single disc
Front Tire	120/70-ZR17
Rear Tire	180/55-ZR17
Seat Height	790 mm (31.1 inches)
Engine Type	4-stroke, 4-cylinder, DOHC
Cooling System	Air/oil-cooled
Rear Suspension	Swingarm, link type, coil spring, oil damped
Fuel Tank Capacity	20 liters
Bore x Stroke	79.0 mm x 59.0 mm
