CHASSIS 5-15
• Remove the oil seal stopper ring.
• Remove the damper rod bolt.
• Remove the inner rod cylinder.
• Remove the oil seal by slowly pulling out the inner tube.
NOTE:
Be careful not to damage the inner tube.
#
The outer and inner tube’s slide metals must be replaced
along with the oil seal and dust seal when assembling
the front fork.
• Remove the following parts.
1 Oil seal
2 Oil seal retainer
3 Outer tube slide metal
4 Inner tube slide metal
5 Oil lock piece

Suzuki GSF1200S 2001 Specifications

General

Displacement	1157 cc
Compression Ratio	9.5:1
Ignition	Electronic ignition (Transistorized)
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Front Brakes	Dual disc
Rear Brakes	Single disc
Front Tire	120/70-ZR17
Rear Tire	180/55-ZR17
Seat Height	790 mm (31.1 inches)
Engine Type	4-stroke, 4-cylinder, DOHC
Cooling System	Air/oil-cooled
Rear Suspension	Swingarm, link type, coil spring, oil damped
Fuel Tank Capacity	20 liters
Bore x Stroke	79.0 mm x 59.0 mm
