Suzuki GSF1200S 2001 User Manual

ENGINE 3-9
• Tighten the oil cooler mounting bolts to the specified torque.
" Oil cooler mounting bolt: 10 N
.
m (1.0 kgf
.
m, 7.0 lb-ft)
• Tighten the oil cooler hose union bolts to the specified torque.
" Oil cooler hose union bolt: 23 N
.
m (2.3 kgf
.
m, 16.5 lb-ft)
$
Use a new gasket washer to prevent oil leakage.
NOTE:
When installing a new exhaust pipe/muffler assembly connector,
remove all of the old sealer from the exhaust pipe and from inside
the muffler. Apply the exhaust gas sealer to both the inside and
outside of the new exhaust pipe/muffler assembly connector.
EXHAUST GAS SEALER: PREMATEX 1372
• Install the exhaust pipe gaskets 1.
$
Be sure to face the tabs A on the exhaust pipe gasket 1
to the inside when installing it.
Muffler mounting bolt: 29 N
.
m (2.9 kgf
.
m, 21.0 lb-ft)
• Tighten the exhaust pipe bolts and muffler mounting bolts to
the specified torque.
" Exhaust pipe bolt: 23 N
.
m (2.3 kgf
.
m, 16.5 lb-ft)

Suzuki GSF1200S 2001 Specifications

General

Displacement	1157 cc
Compression Ratio	9.5:1
Ignition	Electronic ignition (Transistorized)
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Front Brakes	Dual disc
Rear Brakes	Single disc
Front Tire	120/70-ZR17
Rear Tire	180/55-ZR17
Seat Height	790 mm (31.1 inches)
Engine Type	4-stroke, 4-cylinder, DOHC
Cooling System	Air/oil-cooled
Rear Suspension	Swingarm, link type, coil spring, oil damped
Fuel Tank Capacity	20 liters
Bore x Stroke	79.0 mm x 59.0 mm
