4-16 FI SYSTEM DIAGNOSIS
TERMINAL
NO.
CIRCUIT
TERMINAL
NO.
CIRCUIT
Y — l —
Z — m —
[ Tachometer n —
\
Immobilizer communication
[For E-02, 19, 24]
o
Immobilizer communication
[For E-02, 19, 24]
] Fuel pump relay (FP Relay) p —
^ Starter relay q Mode select switch
a Blank r Neutral switch
b — s Clutch position switch
c Cooling fan relay (FAR) t PAIR control solenoid valve (PAIR)
d
Immobilizer indicator light
[For E-02, 19, 24]
u
Secondary fuel injector #4 (#42)
e Primary fuel injector #4 (#41) v Secondary fuel injector #3 (#32)
f Primary fuel injector #3 (#31) w Secondary fuel injector #2 (#22)
g Primary fuel injector #2 (#21) x Secondary fuel injector #1 (#12)
h Primary fuel injector #1 (#11) y Ground
i Ignition coil #3 z Ground
j Ignition coil #2 { Ground for ignition system
k Ignition coil #1 | Ignition coil #4
