CHASSIS 8-25
• Make sure that the height H of the inner rod threads is as fol-
lows.
H: 11 mm (0.43 in)
• Slowly turn the cap bolt completely by hand until the end of
the cap bolt seats on the lock nut.
• Apply fork oil to the O-ring.
• Hold the cap bolt 2 and tighten the lock-nut 3 to the speci-
fied torque.
Inner rod lock-nut: 29 N·m (2.9 kgf-m, 21.0 lb-ft)
• Remove the special tools.
• Install the front fork cap bolt to the outer tube temporarily.
Make sure that the rebound damping force adjuster 1
to the softest position before installing the cap bolt.
