CHASSIS 8-27
Rebound damping force
Fully turn the damping force adjuster 1 clockwise. It is at stiffest
position and turn it out to standard setting position.
(For E-02, 19): 11 clicks out from stiffest position
(For E-03, 24, 28, 33): 9 clicks out from stiffest position
NOTE:
Make sure to check the 1st click position by the last click sound
when turning in the adjuster.
STANDARD FRONT SUSPENSION SETTING
(For E-02, 19)
(For E-03, 24, 28, 33)
FRONT
Spring pre-load
adjuster
Damping force adjuster
Compression Rebound
Solo and
dual riding
4
16 clicks out from
stiffest position
11 clicks out from
stiffest position
FRONT
Spring pre-load
adjuster
Damping force adjuster
Compression Rebound
Solo and
dual riding
4
14 clicks out from
stiffest position
9 clicks out from
stiffest position
Be sure to adjust the spring pre-load and damping
force on both front fork legs equally.
