10-58 SERVICING INFORMATION
SUSPENSION Unit: mm (in)
FUEL + OIL
ITEM STANDARD LIMIT
Front fork stroke 120
(4.92)
—
Front fork spring free length 230.0
(9.06)
225
(8.86)
Front fork oil level (without spring,
outer tube fully compressed)
101
(3.98)
—
Front fork oil type SUZUKI FORK OIL L01 or an equivalent fork oil —
Front fork oil capacity (each leg) 510 ml
(17.2/17.9 US/Imp oz)
—
Front fork spring adjuster 4 th groove from top —
Front fork damping force adjuster
(For E-02, 19)
Rebound 11 clicks out from stiffest position —
Compression 16 clicks out from stiffest position —
Front fork damping force adjuster
(For E-03, 24, 28, 33)
Rebound 9 clicks out from stiffest position —
Compression 14 clicks out from stiffest position —
Rear shock absorber spring pre-set
length
177.6
(6.99)
—
Rear shock absorber damping
force adjuster
Rebound 12 clicks out from stiffest position —
Compression 14 clicks out from stiffest position —
Rear wheel travel 130
(5.1)
—
Swingarm pivot shaft runout
—
0.3
(0.01)
ITEM SPECIFICATION NOTE
Fuel type Use only unleaded gasoline of at least 90 pump
octane (R/2 + M/2).
Gasoline containing MTBE (Methyl Tertiary Butyl
Ether), less than 10% ethanol, or less than 5%
methanol with appropriate cosolvents and corro-
sion inhibitor is permissible.
E-03, 28, 33
Gasoline used should be graded 95 octane or
higher. An unleaded gasoline is recommended.
Others
Fuel tank capacity
Including
reserve
17.5 L
(4.6/3.8 US/lmp gal)
E-33
18 L
(4.8/4.0 US/lmp gal)
Others
Fuel level
indicator light
lighting
Approx. 4.5 L
(1.2/1.0 US/lmp gal)
Engine oil type SAE 10 W-40, API SF/SG or SH/SJ with JASO MA
Engine oil capacity
Change
3.0 L
(3.2/2.6 US/lmp qt)
Filter change
3.3 L
(3.5/2.9 US/lmp qt)
Overhaul
3.6 L
(3.8/3.2 US/lmp qt)
