Sym RS-50 - Body Cover; Mechanism Illustration

12. Body Cover
12-1
Mechanism Illustration .....................12-1
Maintenance Information..................12-2
Front Cover........................................12-3
Handle Cover.....................................12-4
Front Fender......................................12-6
Left & Right Side-Covers..................12-6
Rear Carrier .......................................12-7
Luggage Box .....................................12-7
Center Cover......................................12-8
Body Cover ........................................12-9
Left & Right Side Foot Plates ...........12-10
Floor Panel.........................................12-11
Front under Spoiler...........................12-12
Inner Cover ........................................12-13
Under Cover.......................................12-15
Rear Inner Fender..............................12-15
Mechanism Illustration
Luggage box
Handle rear cover
Front fender
Center cover
Rear fender
Right side cover
Left side cover
Handle cover
Front cover
Front under spoiler
Left-body cover
Right body
cover
Floor panel
Inner box
Foot mat
Seat
Rear Carrier
Battery cover
Right foot plate
Handle side
cover (RH)
Under Cover
Inner rear fender
Tail light set
Rear center cover
Left foot plate
Handle side
cover (LH)
12
Home page
Contents
Inner box lid
