Sym RS-50 - Left & Right Side Foot Plates

12. Body Cover
12-10
Left & Right Side Foot Plates
Removal
Remove the foot plates connection screws & bolt.
(3 screws & 1 bolt on left & right each side)
Remove the rear connection screws. (1 bolt on left
& right each side)
Remove side foot plates.
Installation:
Install according to the reverse procedure of
removal.
Screws x 3
Bolt x 1
This Chapter Contents
Bolt x 1
