12. Body Cover
12-12
Front under Spoiler
Removal
Remove the front fender, front cover.
Remove the front fender, front brake system, and
odometer cable, as well as the front wheel.
.
Remove the inner box screw (left & right each side
x 3), and 1 screw on the left & right each side of
side cover.
Remove 4 screws on the left & right each side of
side cover.
Bend the frame hook slightly straight on the front
under spoiler.
Remove the front under spoiler. (4 screws)
Installation
Install according to the reverse procedure of
removal.
This Chapter Contents
Screws x 3
Screws x 4
Screw x 2
Hook
To Next Page
